Description
FlexP0060 – Booster
The FlexP 0060 has been designed for battery module/pack characterizations.
The continuous maximum current of -50 A/+49 A for a single unit can be extended up to -200 A/+196 A by connecting four units in parallel.
The booster is also highly suitable for Redox Flow Batteries (RFB) or fuel cell stack.
The FlexP0060 is not only a DC instrument, it is also able to perform EIS measurement up to 10 kHz.
The instrument configuration can be easily modified, in-situ, to meet the end-user’s specific requirements. The instrument does not need to be sent back to the factory to be upgraded thanks to the plug and play capability of the booster modules.
Le EC-Lab® interface will automatically detect any new configuration ensuring that the transition to the new upgrade occurs seamlessly
EC-Lab’s stack mode allows the user to measure elements in series within a battery/fuel cell pack. This process is described in application note: AN#59 – A full solution to address battery modules/packs.
Caractéristiques
- Up to 60 V
- Up to -50 A / +49 A
- Up to -200 A / +196 A with 4 units connected
- EIS: up to 10 kHz
- Individual Element measurement within a pack
